Rated speed V
|
0,15 - 2,5 m/s
|
Tripping speed Vmax
|
0,52 ... 4,62 m/s
|
Min. brake force of the governor
|
500 N / 800 N : unidirectional tripping
500 N : bi-directional tripping |
Rope diameter d
|
d = 6,0mm / DB = 200mm
d = 6,5mm / DB = 203mm
|
Max. travel height
|
80m - 120m : unidirectional tripping
120m : bi-directional tripping |
Rated speed V | 0,15 - 2,5 m/s |
Tripping speed Vmax | 0,52 ... 4,62 m/s |
Min. brake force of the governor | 500 N |
Rope diameter d |
d = 6,0mm / DB = 288mm
d = 6,5mm / DB = 291mm d = 8,0mm / DB = 300mm |
Max. travel height | 80m : unidirectional tripping 120m : bi-directional tripping |
Subject to change without notice. Please download the technical catalogue for more information.
